LP2507L290
2.5 Dial Size, 0-3 psi Range, 0.5 Fig. (PSI), 0.1 Div. (PSI). The Miljoco low pressure diaphragm gauge offers the pinnacle in both performance and accuracy for pressure and vacuum applications up to and including 10 psi. Such uses include gas-draft indication, air flow & filtration, leak detection, etc. The LP2507/LP2507L is constructed from a single beryllium-copper diaphragm affixed to a precisionmachined brass plate. This advanced design, coupled with a high-precision, milled-teeth brass movement and nickelsilver pinion and bearing surface, provides the user with a low pressure instrument that is without equal.
TECHNICAL SPECS
CASE: Drawn steel, black finished.
LENS: Polycarbonate, quarter-turn.
DIAL: Aluminum, white finished with black markings.
POINTER: Black non-adjustable.
MOVEMENT: Brass with precision-milled teeth.
DIAPHRAGM: Beryllium copper.
SOCKET: Brass.
CONNECTION: 1/4" NPT, bottom outlet.
RESTRICTOR: 0.013 restrictor on ranges over 10 H2O.
ACCURACY: 1.5% Full Scale (exceeds ASME B40.100
Grade B). Ranges below 30 H2O are 3-1-3%.
PROCESS TEMPERATURE: -40 to 160 degrees F (-40 to 70 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).
Miljoco LP2507L290
TECHNICAL SPECS
CASE: Drawn steel, black finished.
LENS: Polycarbonate, quarter-turn.
DIAL: Aluminum, white finished with black markings.
POINTER: Black non-adjustable.
MOVEMENT: Brass with precision-milled teeth.
DIAPHRAGM: Beryllium copper.
SOCKET: Brass.
CONNECTION: 1/4" NPT, bottom outlet.
RESTRICTOR: 0.013 restrictor on ranges over 10 H2O.
ACCURACY: 1.5% Full Scale (exceeds ASME B40.100
Grade B). Ranges below 30 H2O are 3-1-3%.
PROCESS TEMPERATURE: -40 to 160 degrees F (-40 to 70 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).
Miljoco LP2507L290
$43.36
Ex Tax: $43.36
- Stock:
- Manufacturer: Miljoco
- Model: p47078
- SKU: LP2507L290
