F-JHA-H2

Suitable for flow rate adjustment in semiconductor manufacturing process.

Model type: Union Elbow
Weight: 55.0g
Shipping unit: 1pc.

Resin: PFA, PTFE, and PVDF

Port size
Tube dia. (O.D x I.D): φ6.35mmxφ3.95mm

Specifications
Fluid medium: Liquid(Conditional*1)
Max. operating pressure: 0.7MPa(at 0～60℃)*2
Operating temp. range: 0～100℃

Advantages
Suitable for flow rate adjustment in semiconductor manufacturing process.

High pull-out strength and sealability are realized.
An impact-ring holds the tube firmly.

Easy control of union nut tightening.
A click gauge is incorporated for making an easy check that the union nut is firmly tightened.
