Minimize the pressure drop of other circuit when a workpiece falls down.
Specifications
Fluid medium: Air
Operating pressure range: Positive pressure:0～0.7MPa/Negative pressure:0～-100kPa
Operating temp. range: 0～60℃ (No freezing)
Advantages
Minimize the pressure drop of other circuit when a workpiece falls down.
Fall prevention valve prevents the properly picked up work-piece from falling, even when several vacuum pads are without work-piece, causing vacuum lowering of whole system.
It reduces the vacuum lowering for vacuum pads with work-piece.
