P6098LY02SS
6 Dial Size, 0-15 psi / 0-100 kPa Range, 3 Fig. (PSI), 0.2 Div. (PSI), 10 Fig. (kPa), 2 Fig. (kPa). The Miljoco Models P6098LY-SS is attractively-priced gauge for applications where the process fluid requires stainless steel wetted components. This industrial gauge features a stainless steel case and can be filled with glycerine or silicone to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1% full scale accuracy and is suitable for many industrial processing applications. CAUTION: A coil syphon must be installed on the connection when used on steam applications.
TECHNICAL SPECS
CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Stainless steel, rotary type.
TUBE & SOCKET: 316 Stainless steel.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 250 degrees F
(-40 to 120 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F
(-40 to 60 degrees C).
Miljoco P6098LY02SS
TECHNICAL SPECS
CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Stainless steel, rotary type.
TUBE & SOCKET: 316 Stainless steel.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 250 degrees F
(-40 to 120 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F
(-40 to 60 degrees C).
Miljoco P6098LY02SS
$142.90
Ex Tax: $142.90
- Stock: 2-3 Days
- Manufacturer: Miljoco
- Model: p48388
- SKU: P6098LY02SS
