P2598LZ005SS

2.5 Dial Size, 30"Hg-0-100 psi / -100-700 kPa Range, 30/20 Fig. (PSI), 5/2 Div. (PSI), 200 Fig. (kPa), 10 Fig. (kPa). The Miljoco P2598LZ-SS is a compact industrial gauge for applications where the process fluid requires stainless steel wetted components. This gauge features a stainless steel case and can be filled with glycerine to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1.6% full scale accuracy and is suitable for many industrial and processing applications. CAUTION: A coil syphon must be installed on the connection when used on steam applications.


TECHNICAL SPECS

CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, non-adjustable.
MOVEMENT: Stainless steel.
TUBE & SOCKET: 316 Stainless steel.
CONNECTION: 1/4 NPT bottom outlet. Back outlet, consult factory.
ACCURACY: 1.6% Full Scale (exceeds ASME B40.100
Grade B).
PROCESS TEMPERATURE: -40 to 250 degrees F (-40 to 120 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).


Miljoco P2598LZ005SS
