P150807

1.5 Dial Size, 0 - 200psi/bar Range. An economic line of pressure gauges for general in plant service on air, water, gases, and other light duties An economic line of pressure gauges for general in plant service on air, water, gases, and other light duties suitable for brass gauge components. This instrument has an attractive appearance featuring a highly suitable for brass gauge components. This instrument has an attractive appearance featuring a highly polished chrome plated ring and a dual colored dial face. CAUTION: A coil syphon must be installed on the polished chrome plated ring and a dual colored dial face. CAUTION: A coil syphon must be installed on the connection when used for steam service. connection when used for steam service.


TECHNICAL SPECS

CASE: Black finished C.R.S.
RING: Chrome plated.
LENS: Acrylic.
DIAL: White finished with black markings for psi and blue markings for bars & kPa scale.
POINTER: Black, non-adjustable.
MOVEMENT: Brass.
BOURDON TUBE: Brass.
CONNECTION: 1/8 NPT, back outlet.
ACCURACY: 3-2-3% ANSI B40.1, Grade B.


Miljoco P150807
