  • manufacture_name
  • Part #: P4598LX003

    Price :
    • $24.75

-
+


4.5 Dial Size, 30" Hg-0-30 psi Range, 10/5 Fig. (PSI), 2/1 Div. (PSI). The Miljoco P4598L Contractor's Gauge is attractively priced and meets or exceeds the industry accepted standard for the commercial HVAC and building trades.
This instrument features a stainless steel case and ring, and uses high-temperature solder joints on the tube and socket, allowing it to be used on process fluids up to
200 degrees F. It is well-suited for service on air, water, glycol solutions, and gas. CAUTION: A coil syphon must be installed on the connection when used on steam applications.


TECHNICAL SPECS

CASE: Brightly finished stainless steel.
RING: Stainless steel.
LENS: Acrylic.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET: Phosphor-bronze tube, brass socket.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 200 degrees F (-40 to 93 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).



Miljoco P4598LX003

4.5 Dial Size, 30" Hg-0-30 psi Range, 10/5 Fig. (PSI), 2/1 Div. (PSI). The ...
