P4098LY11
4 Dial Size, 0-600 psi / 0-4000 kPa Range, 50 Fig. (PSI), 10 Div. (PSI), 1000 Fig. (kPa), 50 Fig. (kPa). The Miljoco Models P4098LY is attractivelypriced gauges for applications where the process fluid is compatible with brass wetted components. This industrial gauge features a stainless steel case and can be filled with glycerine or silicone to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1% full scale accuracy and is suitable for many industrial processing applications. CAUTION: A coil syphon must be installed on the connection when used on steam applications.
TECHNICAL SPECS
CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET: Brass.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 200 degrees F (-40 to 93 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).
Miljoco P4098LY11
TECHNICAL SPECS
CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET: Brass.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 200 degrees F (-40 to 93 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).
Miljoco P4098LY11
$68.25
Ex Tax: $68.25
- Stock: 2-3 Days
- Manufacturer: Miljoco
- Model: p48301
- SKU: P4098LY11
