  • manufacture_name
  • Part #: P4098LY06

    Price :
    • $62.33

-
+


4 Dial Size, 0-100 psi / 0-700 kPa Range, 10 Fig. (PSI), 2 Div. (PSI), 100 Fig. (kPa), 20 Fig. (kPa). The Miljoco Models P4098LY is attractivelypriced gauges for applications where the process fluid is compatible with brass wetted components. This industrial gauge features a stainless steel case and can be filled with glycerine or silicone to prolong the life of the internal mechanism when exposed to vibration. It is calibrated to 1% full scale accuracy and is suitable for many industrial processing applications. CAUTION: A coil syphon must be installed on the connection when used on steam applications.


TECHNICAL SPECS

CASE: 300 series stainless steel.
RING: 300 series stainless steel, bayonet type with gasket.
LENS: Polycarbonate.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Brass with precision-milled teeth.
TUBE & SOCKET: Brass.
CONNECTION: 1/4 NPT bottom outlet.
ACCURACY: 1% Full Scale (ASME B40.100 Grade 1A).
PROCESS TEMPERATURE: -40 to 200 degrees F (-40 to 93 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).


Miljoco P4098LY06

4 Dial Size, 0-100 psi / 0-700 kPa Range, 10 Fig. (PSI), 2 Div. (PSI), 100 F...
