  • Part #: P4509LX11

    Price :
    • $85.05

-
+


4.5 Dial Size, 0 - 100psi Range, 100 Fig. (PSI), 10 Div. (PSI). The Miljoco P4509LX is designed to add value to any installation where a highly accurate gauge is required and the process fluid is compatible with brass and bronze. This gauge is furnished standard with a rear flange providing surface or stem mounting, and is furnished with a stainless steel rotary-type movement enhancing service life. The rear of the case can be equipped with an optional blow-out disc as an added safety feature. This gauge is ideally suited for service on air, water, glycol solutions, and gas. CAUTION: A coil syphon must be installed on the connection when used on steam applications.


TECHNICAL SPECS

CASE: Black cast-aluminum with a 3-hole surface-mount rear flange.
RING: Stainless steel.
LENS: Double-strength glass.
DIAL: Aluminum, white finished with black markings.
POINTER: Aluminum, black, micro-adjustable.
MOVEMENT: Stainless steel rotary type.
TUBE & SOCKET: Phosphor-bronze tube, brass socket.
CONNECTION: 1/4 NPT brass, bottom outlet.
ACCURACY: 1/2% Full Scale (ASME B40.100 Grade 2A).
PROCESS TEMPERATURE: -40 to 200 degrees F (-40 to 93 degrees C).
AMBIENT TEMPERATURE: -40 to 140 degrees F (-40 to 60 degrees C).


Miljoco P4509LX11
